Helvia ZEUS 2120CA
€795,00€883,00 (-10%)
100V RMS Output Power: 2x120W
70V RMS Output Power: 2x120W
4-16O RMS Output Power: 2x120W @ 4O
Input Sensitivity: 1V/Gain max @ 0.775V
Input Impedance: 20KO ±10%
HPF Filter: ON = 400Hz-20kHz; OFF = 80-20kHz
Frequency response: 80-20kHz/ 400Hz-20kHz
THD (1W @ 1KHZ): < 0.05%
Damping Factor: >300 @ 100 Hz
Crosstalk: >70dB
S/N Ratio: >85dB
Amplifier Class: Class D
Power Requirements: AC 230V/DC24V
Power Consumption (Average/Peak): 300W
Input Connectors: 3-Pin Female XLR
Output Connectors: 5-Pin Phoenix
Ch Output Connectors: 3-Pin Male XLR
Cooling: Temperature controlled fan
Dimension (WxDxH): 484x400x88 mm
Rack Mount: 2x 19″ Rack Units
Packing Size (WxDxH): 550 x 500 x 170 mm
Net Weight: 9,6 kg
Gross Weight: 11,2 kg
70V RMS Output Power: 2x120W
4-16O RMS Output Power: 2x120W @ 4O
Input Sensitivity: 1V/Gain max @ 0.775V
Input Impedance: 20KO ±10%
HPF Filter: ON = 400Hz-20kHz; OFF = 80-20kHz
Frequency response: 80-20kHz/ 400Hz-20kHz
THD (1W @ 1KHZ): < 0.05% Damping Factor: >300 @ 100 Hz
Crosstalk: >70dB
S/N Ratio: >85dB
Amplifier Class: Class D
Power Requirements: AC 230V/DC24V
Power Consumption (Average/Peak): 300W
Input Connectors: 3-Pin Female XLR
Output Connectors: 5-Pin Phoenix
Ch Output Connectors: 3-Pin Male XLR
Cooling: Temperature controlled fan
Dimension (WxDxH): 484x400x88 mm
Rack Mount: 2x 19″ Rack Units
Packing Size (WxDxH): 550 x 500 x 170 mm
Net Weight: 9,6 kg
Gross Weight: 11,2 kg
