IOS/ANDROID

Common
Type: 2 in/2out or 4 in/2out
Conversion: 24-bit A/D, 24-bit D/A
Sampling Rate: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Power: USB bus powered. 48V operations with iOS devices require battery or DC IN. When connected to an external PSU (iRig PSU 3A, not included), iRig Stream Pro charges the connected iOS lightning device.
Metering: 3x LEDs for overall streaming signal. Peak meter for Mic/Inst input.
Device Connection: mini-DIN
Dimensions: 123 mm/4.84” x 67 mm/2.63” x 40 mm/1.57”
Weight: 146g
Line input
Connector: 2x RCA (unbal.) Left/Right
Nominal Input Level: -10 dBV
Head Room: 10 dB – Level @ max
Input Impedance: 16.5k Ohms
Frequency Response: from 20 Hz to 20 kHz (-1.5 dB)
Microphone Input
Microphone Input: balanced, XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground
Microphone Input Level: from 3.8 mV RMS to 388 mV RMS
Microphone Input Impedance: approx 2 kOhms
Analog Gain Range: 40 dB
Phantom Power: +48 V ± 4 V
Frequency Response:from 20 Hz to 20 kHz (-1 dB) Gain @ minfrom 20 Hz to 20 kHz (-3 dB) Gain @ max
Instrument Input
Instrument Input: unbalanced, Hi-Z, TS 1/4” Jack, Tip: signal / Shield: ground
Instrument Input Level: from 70 mV RMS to 1.8 V RMS
Instrument Input Impedance: 1M Ohms
Analog Gain Range: 28 dB
Frequency Response:from 20 Hz to 20 kHz (-1 dB) Gain @ minfrom 20 Hz to 20 kHz (-3 dB) Gain @ max
Headset/Phones
Connector: 1/8” TRRS jack (CTIA wiring standard)
Supply voltage: > 2,5 V
Microphone gain: Adjustable with numbered thumbwheel
Frequency Response: 20 Hz – 20 kHz
Headphone Level control: numbered thumbwheel
Battery Life
Phantom power On with iOS device: up to 20 hours (Alkaline batteries), with mic input connected to 3.1 mA phantom powered load
Note: all measurements made with Stream Level knob at 0dB.
Package includes
iRig Stream Pro interface
Lightning to mini-DIN connection cable with charging features (60cm/23.62″)
USB C-Type to mini-DIN connection cable (60cm/23.62″)
USB A-Type to mini-DIN connection cable (60cm/23.62″)
2x 1.5V AA battery
Velcro strip
Compatibility

iOS Devices
Compatible with iPhone 12 Pro Max, iPhone 12 Pro, iPhone 12, iPhone 12 mini, iPhone SE (2nd generation), iPhone SE, iPhone 11 Pro Max, iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 11 Pro, iPhone 11, iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone 6, iPad (8th generation), iPad Pro 10.5-inch, iPad Pro 12.9-inch (2nd generation), iPad Pro 9.7-inch, iPad Pro 12.9-inch (1st generation), iPad Air (3rd generation), iPad Air 2, iPad mini (5th generation), iPad (7th generation), iPad (6th generation), iPad (5th generation), iPod touch (7th generation), iPod touch (6th generation).
Also compatible with all newer iPhone, iPad and iPod touch models.
Computers
Mac®: macOS® 10.6 or later. One free USB port.
Windows®: One free USB port. For low latency, the IK Multimedia’s iRig audio driver must be installed.
Android Devices: Compatible with Android devices running Android 5 or later and with USB digital audio capabilities. Micro-USB-OTG mini-DIN cable (sold separately) may be required (depending on device model).

Key Features

For iPhone, iPad, Android and digital cameras
Built-in XLR connector for microphones
Adjustable gain control
+48 V phantom power
50 Hz to 20 kHz frequency response
Headphone output with direct monitoring
Attached 40cm (15.75″) TRRS cable
Auto-sensing 3.5mm output
Powered by 2xAA batteries
On/Off switch
Compatible with all your favorite apps

Technical Specifications

Frequency response: from 50 Hz to 20 KHz
EIN (@gain min): -113.5 dBA
EIN (@ gain max): -92.4dBA
THD+N: -90 dBA / 0,003%
Gain range: 48dB
Phantom max current: 6mA
Battery duration (Alkaline 2xAA): approx 20 hours when phantom is off, approx 7 hours when phantom is on

Includes

iRig Pre 2
2xAA batteries
Velcro strip
Free apps for iOS and Android

Dimensions

Size: 40mm/1.57″ x 110mm/4.33″ x 34mm/1.34″
Weight: 75g/2.65oz (batteries excluded)
Cables length: 40cm/15.75″

iOS and Android Devices
Compatible with iPhone, iPad, iPod touch and Android devices with 1/8″ / 3.5mm jack standard headset input (onboard or via adaptor) compliant with the CTIA/AHJ wiring standard, which is illustrated as follows.

DSLR Cameras
Compatible with most DSLR cameras equipped with 1/8″ / 3.5mm jack microphone input.
