TOA
-
-
TOA BC-900
The BC-900 is a dedicated battery charger for the BP-900 (optional) used in the Chairman Units, and Delegate Units. It permits up to 8 batteries to be simultaneously charged within up to 5 hours.Spec Power Source AC mains
Current Consumption Max. 5 A
Charging Time Approx. 5 hours
Charging Capacity 8 BP-900 batteries (option)
Finish Case: Steel, black, paint
Battery receptacles: PPO resin, black
Dimensions 240 (W) x 70 (H) x 115 (D) mm€1.190,40TOA BC-900
€1.190,40Available in 1-3 days
-
TOA VP-2421 AMPLIFIER 1x420W/100V INPUT MONO WITH VP-200VX MOD
Ενισχυτής συστήματος ανακοινώσεων 1x420W/100V. Ο ενισχυτής ελέγχεται συνεχώς από το σύστημα και σε περίπτωση βλάβης αντικαθίστανται αυτόματα από εφεδρικό ενισχυτή, ο οποίος πρέπει οπωσδήποτε να είναι εγκατεστημένος σύμφωνα με το πρότυπο ΕΝ-60849.€1.488,00Available in more than 30 days
-
TOA VP-2241 AMPLIFIER 1x240W/100V INPUT MONO WITH VP-200VX MOD
Ενισχυτής συστήματος ανακοινώσεων 1x240W/100V. Ο ενισχυτής ελέγχεται συνεχώς από το σύστημα και σε περίπτωση βλάβης αντικαθίστανται αυτόματα από εφεδρικό ενισχυτή, ο οποίος πρέπει οπωσδήποτε να είναι εγκατεστημένος σύμφωνα με το πρότυπο ΕΝ-60849.€992,00Available in more than 30 days
-
TOA VP-2122 AMPLIFIER 2x120W/100V INPUT MONO WITH VP-200VX MOD
Ενισχυτής συστήματος ανακοινώσεων 2x120W/100V. Ο ενισχυτής ελέγχεται συνεχώς από το σύστημα και σε περίπτωση βλάβης αντικαθίστανται αυτόματα από εφεδρικό ενισχυτή, ο οποίος πρέπει οπωσδήποτε να είναι εγκατεστημένος σύμφωνα με το πρότυπο ΕΝ-60849.€992,00Available in more than 30 days
-
TOA VP-2064 AMPLIFIER 4x60W/100V INPUT MONO WITH VP-200VX MOD
The VP-2064 Power Amplifier features a 60 W-by-4 channels configuration, and uses the VP-200VX Power Amplifier Module per channel.Spec Power Source 28 V DC
Current Consumption (EN60065) 4.8 A in total
Rated Output Power 60 W x 4
Output Voltage/Impedance 100 V/167 ohms, 70 V/83 ohms, 50 V/41 ohms
(selectable by the internal wiring change)
Number of Channels 4
Input Specified by input module VP-200VX
Number of Module Slots 4, usable module: VP-200VX
Output Power amplifier output (speaker line):
M3.5 screw terminal, distance between barriers: 8.8 mm
Frequency Response 40 – 16,000 Hz, +/-3 dB (at 1/3 rated output)
Distortion Under 1% (at rated output, 1 kHz)
S/N Ratio Over 80 dB
Dimensions 482 (W) x 88.4 (H) x 340.5 (D) mm€480,21€837,00Available in 1-3 days
-
TOA VP-200VX-BGM INPUT MODULE FOR VP+BGM
Input module for VP+BGM€79,36Available in more than 30 days
-
TOA VP-200VX INPUT MODULE FOR VP SERIES
Amplifier input module for VX-2000€39,68Available in more than 30 days
-
TOA TH-660 HORN SPEAKER 110dB IP-65
TOA’s TH-660 is a speaker horn to be used in combination with an optional driver unit. Its powder-coated finish, and stainless steel screws ensure the unit’s weatherproof capability.
Applicable Drivers TU-630, TU-630M, TU-650, TU-650M
Sensitivity 110 dB (1 W, 1 m) (When operated with a driver.)
Frequency Response 200 – 6,000 Hz (When operated with a driver.)
Dust/Water Protection IP65 (When operated with a driver.)€130,00€143,84TOA TH-660 HORN SPEAKER 110dB IP-65
€130,00€143,84Available in more than 30 days
-
TOA TH-650 HORN SPEAKER 110dB IP-65
TOA’s TH-650 is a speaker horn to be used in combination with an optional driver unit. Its powder-coated finish, and stainless steel screws ensure the unit’s weatherproof capability.Spec Applicable Drivers TU-630, TU-630M, TU-650, TU-650M
Sound Pressure Level 110 dB (1 W, 1 m) (When operated with a driver.)
Frequency Response 200 – 6,000 Hz (When operated with a driver.)
Water Protection IP65 (When operated with a driver.)€100,01€110,36TOA TH-650 HORN SPEAKER 110dB IP-65
€100,01€110,36Available in 1-3 days
-
TOA SC-630M HORN SPEAKER 70V/100V 30W 113dB IP-65
TOA’s SC-630M is a compact, highly intelligible speaker suited to public address announcement applications. Its external speaker component finished with powder coating, and stainless steel bracket and screws ensure the unit’s weatherproof capability.Spec Rated Input 30 W
Line Voltage 100 V line or 70 V line
Rated Impedance 100 V line: 330 ohms (30 W), 670ohms (15 W), 1 kohms (10 W), 2 kohms (5 W)
70 V line: 170 ohms (30 W), 330 ohms (15 W), 670 ohms (7.5 W),
1 kohms (5 W), 2 kohms (2.5 W)
Sound Pressure Level 113 dB (1 W, 1 m at 500 to 2,500 Hz peak level)
Frequency Response 250 – 10,000 Hz
Sensitivity when used as Microphone (0 dB=1 mW/10 dynes/cm ) -20 dB at 1 kHz
Water Protection IP65
Finish Horn flare: Aluminum, off-white, powder coating
Reflector horn and rear cover: ABS resin, off-whiteDimensions 285 (W) x 227 (H) x 277 (D) mm
€89,73€99,20TOA SC-630M HORN SPEAKER 70V/100V 30W 113dB IP-65
€89,73€99,20Available in more than 30 days
-
TOA SC-630 HORN SPEAKER 8Ω 30W 113dB IP-65
TOA’s SC-630 is a compact, highly intelligible speaker suited to public address announcement applications. Its external speaker component finished with powder coating, and stainless steel bracket and screws ensure the unit’s weatherproof capability.Spec Rated Input 30 W (Mobile Mount use: 15 W)
Rated Impedance 8 ohms
Sound Pressure Level 113 dB (1 W, 1 m at 500 to 2,500 Hz peak level)
Frequency Response 250 – 10,000 Hz
Sensitivity when used as Microphone (0 dB=1 mW/10 dynes/cm ) -20 dB at 1 kHz
Water Protection IP65
Polarity Hot: Black, Com: White
Finish Horn flare: Aluminum, off-white, powder coating
Reflector horn and rear cover: ABS resin, off-white
Bracket, screws and bolts: Stainless steel
Speaker cable: Polyvinyl chloride insulated cabtyre cable
(6 mm in diameter, 600 mm in length)
Dimensions 285 (W) x 227 (H) x 277 (D) mm€72,92€80,60TOA SC-630 HORN SPEAKER 8Ω 30W 113dB IP-65
€72,92€80,60Available in 1-3 days
-
TOA SC-615M HORN SPEAKER 70V/100V 15W/15W 112dB IP-65
TOA’s SC-615M is a compact, highly intelligible speaker suited to public address announcement applications. Its external speaker component finished with powder coating, and stainless steel bracket and screws ensure the unit’s weatherproof capability.Spec Rated Input 15 W
Line Voltage 100 V line or 70 V line
Rated Impedance 100 V line: 670 ohms (15 W), 1 kohms (10 W), 2 kohms (5 W), 3.3 kohms (3 W)
70 V line: 330 ohms (15 W), 670 ohms (7.5 W), 1 kohms (5 W),
2 kohms (2.5 W), 3.3 kohms (1.5 W)
Sound Pressure Level 112 dB (1 W, 1 m at 500 to 2,500 Hz peak level)
Frequency Response 280 – 12,500 Hz
Sensitivity when used as Microphone (0 dB=1 mW/10 dynes/cm ) -22 dB at 1 kHz
Water Protection IP65
Finish Horn flare: Aluminum, off-white, powder coating
Reflector horn and rear cover: ABS resin, off-white
Bracket, Screws and bolts: Stainless steel
Speaker cable: Polyvinyl chloride insulated cabtyre cable
(6 mm in diameter, 600 mm in length)
Dimensions 222 (W) x 179 (H) x 234 (D) mm€72,83€80,60Available in 1-3 days
-
TOA SC-615 HORN SPEAKER 8Ω 15W 112dB IP-65
TOA’s SC-615 is a compact, highly intelligible speaker suited to public address announcement applications. Its external speaker component finished with powder coating, and stainless steel bracket and screws ensure the unit’s weatherproof capability.Spec Rated Input 15 W (Mobile Mount use: 10 W)
Rated Impedance 8 ohms
Sound Pressure Level 112 dB (1 W, 1 m at 500 to 2,500 Hz peak level)
2 280 – 12,500 Hz
Sensitivity when used as Microphone (0 dB=1 mW/10 dynes/cm ) -22 dB at 1 kHz
Water Protection IP65
Polarity Hot: Black , Com: White
Finish Horn flare: Aluminum, off-white, powder coating
Reflector horn and rear cover: ABS resin, off-white
Bracket, screws and bolts: Stainless steel
Speaker cable: Polyvinyl chloride insulated cabtyre cable
(6 mm in diameter, 600 mm in length)
Dimensions 222 (W) x 179 (H) x 234 (D) mm€58,28€64,48TOA SC-615 HORN SPEAKER 8Ω 15W 112dB IP-65
€58,28€64,48Available in 1-3 days
-
TOA PJ-200W PROJECTOR SPEAKER 20W 6.5” 100V 92dB
20W projection speaker
Rated Input 20 W (50 V, 70 V, 100 V Line)
Input Impedance 100 V Line : 500 ohms (20 W), 1 kohms (10 W), 2 kohms (5 W)
70 V Line : 250 ohms (20 W), 500 ohms (10 W), 1 kohms (5 W), 2 kohms (2.5W)
50 V Line : 125 ohms (20 W), 250 ohms (10 W), 500 ohms (5 W), 1 kohms (2.5 W),
2 kohms (1.25 W)
Preset Impedance 500 ohms
Sound Pressure Level 95 dB (1 m, 1 W) at 1 kHz
Speaker Diameter 16 cm
Frequency Range 50 – 20,000 Hz
Finish Cabinet, Cover : ABS Resin, Off-White
Bracket : SPCC, Off-White
Dimensions (WxHxD) 200 x 255 x 250 mm€57,60€95,48TOA PJ-200W PROJECTOR SPEAKER 20W 6.5” 100V 92dB
€57,60€95,48Available in 1-3 days
-
-
TOA PC-3WR CEILING SPEAKER 3W 100V 88dB
The TOA PC-3WR is a completely-sealed, flush-mounted ceiling speaker employing a high power handling, splash-proof, small full-range speaker. It can be quickly installed by means of a spring catch system, reducing labor in construction work. Its ideal applications include washrooms, locker rooms of the pool, and other humid locations.Spec Rated Power 3 W, 1 W
Rated Impedance 3.3 kohms (3 W), 10 kohms (1 W)
Sound Pressure Level 88 dB (1 W, 1 m)
Frequency Response 180 – 20,000 Hz
Finish Frame and case: ABS resin, off-white
Punching net: stainless steel
Dimensions 180 x 120 (D) mm€112,00€124,00TOA PC-3WR CEILING SPEAKER 3W 100V 88dB
€112,00€124,00Available in more than 30 days
-
TOA PC-2668 CEILING SPEAKER 6W 5” 100V 90dB
The TOA PC-2668 speaker can be mounted (exposed installation) to the ceiling where flush mounting is impossible. It can be easily installed thanks to its spring catch method. Push-in connector allows quick wire connection, and speaker lines can be bridged by bridging terminals. The supplied bracket can be mounted to a flush-mount pull box.Spec Rated Input 6 W (for 100 V Line), 3 W (for 70 V Line)
Rated Impedance 100 V Line: 1.7 kohms (6 W), 3.3 kohms (3 W),
(6.7 kohms (1.5 W), 13 kohms (0.8 W): Internal wiring must be changed)
70 V line: 1.7 kohms (3 W), 3.3 kohms (1.5 W),
(6.7 kohms (0.8 W), 13 kohms (0.4 W): Internal wiring must be changed)
Sound Pressure Level 90 dB (1 W, 1 m, 330 – 3,300 Hz Pink noise)
Frequency Response 100 – 16,000 Hz
Speaker Component 12 cm dynamic cone-type speaker
Finish Baffle: ABS resin, off-white (RAL 9010 or equivalent color)
Dimensions 260 x 92 (D) (Exposed section) mm€17,26€31,00TOA PC-2668 CEILING SPEAKER 6W 5” 100V 90dB
€17,26€31,00Available in 1-3 days
-
TOA GS-302 GARDEN SPEAKER FULLRANGE 30W,100V 5” 87dB IPX4
The GS-302 is a compact Garden Speaker ideal for paging and background music broadcast in such places as gardens, theme parks and resort facilities. Corrosion resistant material is adopted to the speaker exterior, ensuring prolonged use of the speaker in a water-splashed environment. The appearance of Garden Speaker is designed so inconspicuous that the speaker can be installed in shrubberies of garden blending with the surroundings.Spec Rated Input 30 W (100 V line), 15 W (70 V line)
Rated Impedance 100 V line: 330 ohms (30 W), 670 ohms (15 W), 1 kohms (10 W), 2 kohms (5 W), 3.3 kohms (3 W)
70 V line: 330 ohms (15 W), 670 ohms (7.5 W), 1 kohms (5 W), 2 kohms (2.5 W), 3.3 kohms (1.5 W)
Sensitivity 87 dB (1 W, 1 m)
Frequency Response 100 – 8,000 Hz
Speaker Component 12 cm splash-proof cone-type
Water Capability Equivalent to IPX4
Finish Top cover and base: FRP resin, dark gray, semi-gloss, paint
Speaker panel: ABS resin, dark gray, semi-gloss, paint
Legs: Aluminum, dark gray, semi-gloss, paint
Dimensions 270 x 335 (H) mm€168,00€186,00TOA GS-302 GARDEN SPEAKER FULLRANGE 30W,100V 5” 87dB IPX4
€168,00€186,00Available in 1-3 days
-
TOA F-2852C CEILING SPEAKER 180W 8Ω/100V 91dB
The F-2852C ceiling and wall-mounted speaker covers a wide area and can be used for 25, 70 and 100 V line applications. Well-balanced sound can be heard uniformly at any location.Spec Enclosure Bass – reflex type
Related Input 60W
Power Handling Capacity Continuous pink noise: 90W (8 ohms), 60W (16 ohms) Continuous program: 180W (8 ohms), 120W (16 ohms)
Impedance 100V line: 170 ohms (60W), 330 ohms (30W), 670 ohms(15W), 3.3 kohms(3W)
Impedance: Low (adjustable) 16 ohms, 8 ohms
Sound Pressure Level 91 dB (1W, 1m)
Frequency Response 60-20,000 Hz (-10 dB), 45-20,000 Hz (-20 dB)
Speaker Component High frequency: Dome-type, Low frequency: 16 cm cone-type€252,01€279,00TOA F-2852C CEILING SPEAKER 180W 8Ω/100V 91dB
€252,01€279,00Available in more than 30 days
-
TOA F-2352SC CEILING SPEAKER 18W 8Ω/100V 89dB
The F-2352SC ceiling and wall-mounted speaker covers an extremely wide area and can be used for 25, 70 and 100 V line applications. Well-balanced sound can be heard uniformly at any location.Spec Related Input 6W
Power Handling Capacity Continuous pink noise: 9W (8 ohms), 6W (16 ohms) Continuous program: 18W (8 ohms), 12W (16 ohms)
Impedance 100V line: 1.7 kohms (6W), 3.3 kohms (3W), 10 kohms (1W), 20 kohms (0.5W)
Impedance: Low (adjustable) 16 ohms, 8 ohms
Sound Pressure Level 89 dB (1W, 1m)
Frequency Response 80-20,000 Hz (-10 dB), 50-20,000 Hz (-20 dB)
Speaker Component High frequency: Balanced dome-type, Low frequency: 12 cm cone-type€57,87€93,00TOA F-2352SC CEILING SPEAKER 18W 8Ω/100V 89dB
€57,87€93,00Available in 1-3 days
-
TOA F-2352C CEILING SPEAKER 120W 8Ω/100V 90dB
The F-2352C ceiling and wall-mounted speaker covers an extremely wide area and can be used for 25, 70 and 100 V line applications. Well-balanced sound can be heard uniformly at any location.Spec Enclosure Bass – reflex type
Related Input 30W
Power Handling Capacity Continuous pink noise: 60W (8 ohms), 30W (16 ohms) Continuous program: 120W (8 ohms), 60W (16 ohms)
Impedance 100V line: 330 ohms (30W), 1 kohms (10W), 3.3 kohms(3W), 10 kohms(1W)
Impedance: Low (adjustable) 16 ohms, 8 ohms
Sound Pressure Level 90 dB (1W, 1m)
Frequency Response 70-20,000 Hz (-10 dB), 50-20,000 Hz (-20 dB)
Speaker Component High frequency: Balanced dome-type, Low frequency: 12 cm cone-type€191,00€210,80TOA F-2352C CEILING SPEAKER 120W 8Ω/100V 90dB
€191,00€210,80Available in more than 30 days
-
TOA F-1522SC CEILING SPEAKER 18W 8Ω/100V 88dB
The F-1522SC ceiling and wall-mounted speaker covers an extremely wide area and can be used for 25, 70 and 100 V line applications. Well-balanced sound can be heard uniformly at any location.Spec Related Input 6W
Power Handling Capacity Continuous pink noise: 9W (8 ohms), 6W (16 ohms) Continuous program: 18W (8 ohms), 12W (16 ohms)
Impedance 100V line: 1.7 kohms (6W), 3.3 kohms (3W)
Impedance: Low (adjustable) 16 ohms, 8 ohms
Sound Pressure Level 88 dB (1W, 1m)
Frequency Response 65-18,000 Hz (-10 dB), 45-20,000 Hz (-20 dB)
Speaker Component 10 cm cone-type€64,46€91,76TOA F-1522SC CEILING SPEAKER 18W 8Ω/100V 88dB
€64,46€91,76Available in more than 30 days
-
TOA F-122C CEILING SPEAKER 120W 8Ω/100V 90dB
The F-122C ceiling and wall-mounted speaker covers an extremely wide area and can be used for 25, 70 and 100 V line applications. Well-balanced sound can be heard uniformly at any location.Spec Enclosure Bass reflex type
Related Input 30W
Power Handling Capacity Continuous pink noise: 60W (8 ohms), 30W (16 ohms) Continuous program: 120W (8 ohms), 60W (16 ohms)
Impedance 100V line: 330 ohms (30W), 1 kohms (10W), 3.3 kohms(3W), 10 kohms(1W)
Impedance: Low (adjustable) 16 ohms, 8 ohms
Sound Pressure Level 90 dB (1W, 1m)
Frequency Response 70-20,000 Hz (-10 dB), 50-20,000 Hz (-20 dB)
Speaker Component 12 cm cone-type€83,54€155,00TOA F-122C CEILING SPEAKER 120W 8Ω/100V 90dB
€83,54€155,00Available in 1-3 days
Spec Power Source AC mains
Power Consumption 72 W
Input MIC: -60 dB, 600 ohms, unbalanced, phone jack
AUX: -20 dB, 10 kohms, unbalanced, phone jack
Output REC: -20 dB, 10 kohms, unbalanced, phone jack, RCA pin jack
HEADPHONE: Mini jack
Number of Connectable 64 units
Infrared Transmitter/Receiver 4 units (up to 16 units by using four Distributors)
External Control Terminal 4 BNC jacks
I/O Terminal D-sub connector (9 P, male)
Finish Panel: Surface-treated steel plate, gray metallic, paint, semi-gloss
